You are at > Home > Laptop Screens > Asus LCDs (All) > Asus R series
×
Enlarged Image
30 Pins - 19mm wide connector


Error retrieving reviews from the server.

ASUS R410U HD Replacement Laptop Screen

SKU
1947075
Condition
NEW, Class 1 (ISO-9241)
Size
14.0"
Resolution
1366X768 (HD) 768p
Backlight
LED
Finish
Matte (Anti-Glare)
Connector
30 PIN EDP (bottom right)
Connector Pitch
0.5mm (Large)
Display Mode
IPS
Display Mode
TN (Twisted Nematic)
Screen Bezel
ASUS NanoEdge™ Screen
Screen Bezel
Narrow Border/Narrow Bezel
 ⓘ Specifications Help
Warning: There may be more than one screen type for your computer. You must choose the correct type. See other options.
Out Of Stock

You'll Also Need:
LCD Mounting Strips      Stretch Release Tape£4.99+VAT (What's this?) Stretch Adhesive Tape is a special LCD tape that can be removed easily (unlike double-sided tape), by pulling tabs at the end of the tape.
Have you got the right product?

The currently selected product on this page is a 14.0" 1366X768 (HD) with a LED backlight and a 30 Pin signal, bottom right connector, with a 0.5mm connector pitch.

This Asus computer has other screen types fitted. You must make sure you purchase the correct one which uses the same resolution and connector type.

Can I Upgrade My Screen?    How do I Order By Screen Model?

Prices shown include UK VAT

 Variations of Asus R series screens
Type
Backlight
Price
Trade

 ASUS R410U 14.0 FULL HD
Matte. Bottom right connector 30 pins (0.5mm)
14.0"
FULL-HD
1920x1080

LED

£44.34

£41.23



Legend:
    Available to buy online
    Unavailable
Asus R series replacement laptop LCD screen
ASUS R410U 14.0 HD LAPTOP SCREEN
14.0"
1366X768
HD
LED
30 Pin/19mm

Class I Display for ASUS laptops
This is a replacement screen for the Asus R410u (HD) computer. Class I and fully compatible LCD display part.

Asus R series LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 14.0" inches diagonally (not including the frame) and has a maximum resolution of 1366X768 (or is known as HD resolution or 768p).

Technical data for the Asus R series LCD.
This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles.

100% Compatible part.
For the Asus R410u (HD).

Easy Mount Display.
This slimline, Narrow-Bezel ASUS LCD features an ultra-thin frame, that requires no awkward screws, and can be securely mounted, to the laptop's top lid using LCD mounting adhesive strips. The LCD is easily removed if needed without voiding your warranty. (strips available separately).

Asus R410u (hd) Screen Installation Video
