You are at > Home > Laptop Screens > Asus LCDs (All) > ROG Gaming > Rog Zephyrus
×
Enlarged Image
40 Pins - 21mm wide connector


Error retrieving reviews from the server.

ASUS ROG ZEPHYRUS DUO 15 SE GX551 Series Full-HD 300hz Replacement Laptop Screen
( Without Touch Glass )

SKU
1777292
Condition
NEW, Class 1 (ISO-9241)
Size
15.6"
Resolution
1920x1080 (FHD) 1080p
Backlight
LED
Touch Screen
NO
Touch Glass
Not included
Finish
Matte (Anti-Glare)
Connector
40 PIN EDP (bottom right)
Connector Pitch
0.4mm (Small)
Frame Rate
300hz Refresh
Display Mode
IPS
Screen Bezel
Narrow Border/Narrow Bezel
 ⓘ Specifications Help
Alternative Technology Available
LQ156M1JWxx 240HZ
360HZ IPS
165HZ
Warning: There may be more than one screen type for your computer. You must choose the correct type. See other options.
£101.94
 + Shipping Costs
Quantity:
Order in 69 hours 53 mins 52 secs for UK delivery Tuesday By 1PM

You'll Also Need:
LCD Mounting Strips      Stretch Release Tape£4.99+VAT (What's this?) Stretch Adhesive Tape is a special LCD tape that can be removed easily (unlike double-sided tape), by pulling tabs at the end of the tape.
Have you got the right product?

The currently selected product on this page is a 15.6" 1920x1080 (FULL HD) with a LED backlight and a 40 Pin signal, bottom right connector, with a 0.4mm connector pitch.

This Rog computer has other screen types fitted. You must make sure you purchase the correct one which uses the same resolution and connector type.

Can I Upgrade My Screen?    How do I Order By Screen Model?

Prices shown include UK VAT

 Variations of Rog Zephyrus screens
Type
Backlight
Price
Trade



Legend:
    Available to buy online
    Unavailable
Rog Zephyrus replacement laptop LCD screen
ASUS ROG ZEPHYRUS DUO 15 SE GX551 SERIES 15.6 FULL HD 300HZ LAPTOP SCREEN NO DIGITIZER
15.6"
1920x1080
FULL HD
LED 300hz
40 Pin/21mm

Class I Display for ASUS laptops
This is a replacement screen for the Asus Rog Zephyrus Duo 15 Se Gx551 (fhd) (300hz) computer. Class I and fully compatible LCD display part.

Rog Zephyrus LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1920x1080 (or is known as FULL HD resolution or 1080p).

Technical data for the Rog Zephyrus LCD.
This screen's backlight is powered by LED backlight technology. The signal connector on this LCD is 40 pin and is an eDP displayport, with a 0.4mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. Special features: 300hz refresh rate. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles.

100% Compatible part.
For the Asus Rog Zephyrus Duo 15 Se Gx551 (fhd) (300hz) . This display will replace many screen makes and models, including (but not limited to), the following part codes: 18010-15690100   TL156VDXP01-01   B156HAN12.0

Easy Mount Display.
This slimline, Narrow-Bezel ASUS LCD features an ultra-thin frame, that requires no awkward screws, and can be securely mounted, to the laptop's top lid using LCD mounting adhesive strips. The LCD is easily removed if needed without voiding your warranty. (strips available separately).

Not Touchscreen. Raw LCD panel only.
Rog Zephyrus screens can sometimes come touch screen enabled, this product is a non-touchscreen model. We are supplying the raw LCD panel only without any accompanying front touch glass overlay (digitizer). If your laptop has a screen and a glass covering providing touch screen features you will need the raw LCD and the digitizer glass together. Professionals can separate the old digitizer with a heat-gun (if not damaged), and fit it to the new display. If your laptop is not a touchscreen model, this is the correct product for you.

Cost of ASUS screen.
Asus Rog Zephyrus Duo 15 Se Gx551 (fhd) (300hz) screen replacement cost is just £101.94 plus shipping.

Warranty
We give an industry leading 2 year warranty on all our high quality ASUS replacement laptop screens. Terms and conditions apply.

Fast Delivery
UK and Europe only.



Certified Screen Replacement5 Star Rated Icon

Asus Rog Zephyrus Duo 15 Se Gx551 (fhd) (300hz) Screen Installation Video

Don't like videos? See our Step by Step generic screen replacement instructions.
See how to find out which model of screen you have.

Warning!!

This screen is only for devices with 15.6" displays @ 1920x1080 (FULL HD) resolution with a LED backlight and a 40 Pin signal, bottom right connector, with a 0.4mm connector pitch.

This product is not for touch screen devices. [ Info ⓘ ]

There are different screen type choices for your device on this page. You must choose the correct type. If you are unsure which type to choose, we recommend removing your old screen and searching for the screen model number instead.
