You are at > Home > Laptop Screens > Asus LCDs (All) > ROG Gaming > Rog Zephyrus
×
Enlarged Image
30 Pins - 19mm wide connector


Error retrieving reviews from the server.

ASUS ROG ZEPHYRUS GX501V Replacement Laptop Screen

SKU
1265790
Condition
NEW, Class 1 (ISO-9241)
Size
15.6"
Resolution
1920X1080 (FHD) 1080p
Backlight
LED
Finish
Matte (Anti-Glare)
Connector
30 PIN EDP (bottom right)
Connector Pitch
0.5mm (Large)
Frame Rate
120hz Refresh
Display Mode
TN (Twisted Nematic)
 ⓘ Specifications Help
This screen has a Matte finish. We can also supply it in:
Glossy / Glare
Alternative Technology Available
60HZ TN
60HZ IPS
Out Of Stock
Rog Zephyrus replacement laptop LCD screen
ASUS ROG ZEPHYRUS GX501V 15.6 LAPTOP SCREEN
15.6"
1920X1080
FULL HD
LED 120hz
30 Pin/19mm

Class I Display for ASUS laptops
This is a replacement screen for the Asus Rog Zephyrus GX501V computer. Class I and fully compatible LCD display part.

Rog Zephyrus LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1920X1080 (or is known as FULL HD resolution or 1080p).

Technical data for the Rog Zephyrus LCD.
This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. Special features: 120hz which enables 3D technology.

Asus Rog Zephyrus Gx501v Screen Installation Video

Don't like videos? See our Step by Step generic screen replacement instructions.
See how to find out which model of screen you have.
