You are at > Home > Replacement LCD parts > AUO LCDs (All) > AUO 16.0"
×
Enlarged Image
40 Pins - 20mm wide connector


Error retrieving reviews from the server.

AUO B160QAN02.0 Replacement LCD Screen Part

SKU
2515075
Condition
NEW, Class 1 (ISO-9241)
Size
16.0"
Resolution
2560X1600 (WQXGA)
Backlight
LED
Finish
Matte (Anti-Glare)
Connector
40 PIN EDP (bottom right)
Connector Pitch
0.4mm (Small)
Frame Rate
165hz Refresh
Display Mode
IPS
Colours
High Gamut 100% sRGB
NTSC
72%
 ⓘ Specifications Help
£77.94
 + Shipping Costs
Quantity:
Order in the next 0 Minutes for UK delivery Friday By 1PM

You'll Also Need:
LCD Mounting Strips      Stretch Release Tape£4.99+VAT (What's this?) Stretch Adhesive Tape is a special LCD tape that can be removed easily (unlike double-sided tape), by pulling tabs at the end of the tape.
AUO 16.0 inch LCD replacement laptop LCD screen
AU OPTRONICS AUO B160QAN02.0 16.0
16.0"
2560X1600
WQXGA
LED 165hz
40 Pin/20mm

Class I Display - 100% Compatibility for AUO screen replacement.
This item is an LCD compatible with Auo B160QAN02.0. For more information about what we're sending please see the Buyer's Guide tab. This is a class I screen, and guaranteed to perfectly replace your original display LCD display part.

AUO 16.0" LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 16.0" inches diagonally (not including the frame) and has a maximum resolution of 2560X1600 (or is known as WQXGA resolution ).

Technical data for the AUO 16.0" LCD.
This screen's backlight is powered by LED backlight technology. The signal connector on this LCD is 40 pin and is an eDP displayport, with a 0.4mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. Special features: 165hz refresh rate. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles.

High Quality Display.
This is the AUO 16.0" DCI-P3 Display, boasting 100% sRGB and 72% NTSC coverage.

Easy Mount Display.
This slimline, Narrow-Bezel AUO LCD features an ultra-thin frame, that requires no awkward screws, and can be securely mounted, to the laptop's top lid using LCD mounting adhesive strips. The LCD is easily removed if needed without voiding your warranty. (strips available separately).

Cost of AUO screen.
Auo B160QAN02.0 screen replacement cost is just £77.94 plus shipping.

Warranty
We give an industry leading 2 year warranty on all our high quality AUO replacement laptop screens. Terms and conditions apply.

Fast Delivery
UK and Europe only.



Certified Screen Replacement5 Star Rated Icon

Universal Laptop Screen Installation Video

152,019 views • 23 May 2021  |  Slow Playback? Standard Quality
