Enlarged Image
30 Pins - 19mm wide connector


Error retrieving reviews from the server.

ChiMei Innolux N156HCG GQ1 Replacement LCD Screen Part

SKU
1507100
Condition
NEW, Class 1 (ISO-9241)
Size
15.6"
Resolution
1920X1080 (FHD) 1080p
Backlight
LED
Finish
Matte (Anti-Glare)
Connector
30 PIN EDP (bottom right)
Connector Pitch
0.5mm (Large)
Display Mode
IPS
 ⓘ Specifications Help
£56.34
 + Shipping Costs
Quantity:
ⓘ  Christmas Delivery, see when we are shipping over Christmas & New Year.

You'll Also Need:
LCD Mounting Strips      Stretch Release Tape£4.99+VAT (What's this?) Stretch Adhesive Tape is a special LCD tape that can be removed easily (unlike double-sided tape), by pulling tabs at the end of the tape.
CMO 15.6 inch LCD parts replacement laptop LCD screen
CHI MEI N156HCG GQ1 15.6
15.6"
1920X1080
FULL HD
LED
30 Pin/19mm

Class I Display - 100% Compatibility for CMO INNOLUX screen replacement.
This item is an LCD compatible with Chi Mei N156hcg GQ1. For more information about what we're sending please see the Buyer's Guide tab. This is a class I screen, and guaranteed to perfectly replace your original display LCD display part.

CMO 15.6" LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1920X1080 (or is known as FULL HD resolution or 1080p).

Technical data for the CMO 15.6" LCD.
This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles.

Cost of CMO INNOLUX screen.
Chi Mei N156hcg GQ1 screen replacement cost is just £56.34 plus shipping.

Warranty
We give an industry leading 2 year warranty on all our high quality CMO INNOLUX replacement laptop screens. Terms and conditions apply.

Fast Delivery
UK and Europe only.



Certified Screen Replacement5 Star Rated Icon

Universal Laptop Screen Installation Video

149,683 views • 23 May 2021  |  Slow Playback? Standard Quality
