Enlarged Image
40 Pins - 21mm wide connector


Error retrieving reviews from the server.

HP 15 DW0035CL 6KL72UA Replacement Laptop Screen

SKU
1454448
Condition
NEW, Class 1 (ISO-9241)
Size
15.6"
Resolution
1366X768 (HD) 768p
Backlight
LED
Touch Screen
YES
Touch Type
OnCELL
Finish
BrightView™ / Glossy (Glare)
Connector
40 PIN EDP (bottom right)
Connector Pitch
0.4mm (Small)
Display Mode
TN (Twisted Nematic)
Screen Bezel
Narrow Border/Narrow Bezel
 ⓘ Specifications Help
Out Of Stock
HP 15 DWxxxxxx models replacement laptop LCD screen
HP NOTEBOOK PC 15 DW0035CL 6KL72UA 15.6 LAPTOP SCREEN
15.6"
1366X768
HD
LED
Touch Screen
40 Pin/21mm

Class I Display for HP laptops
This is a replacement screen for the Hp Notebook Pc 15 Dw0035cl 6KL72UA computer. Class I and fully compatible LCD display part.

HP 15 DWxxxxxx models LCD specifications.
We have these screens with a GLOSS (Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1366X768 (or is known as HD resolution or 768p).

Technical data for the HP 15 DWxxxxxx models LCD.
This screen's backlight is powered by LED backlight technology. The signal connector on this LCD is 40 pin and is an eDP displayport, with a 0.4mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. This is a touch screen that includes the digitizer.

Built in Touchscreen.
This HP display conveniently includes a built in ON-CELL Touch screen digitizer. There no additional parts for the touchscreen feature to function, on your Hp Compaq Notebook Pc 15 Dw0035cl 6KL72UA laptop.

Easy Mount Display.
This slimline, Narrow-Bezel HP LCD features an ultra-thin frame, that requires no awkward screws, and can be securely mounted, to the laptop's top lid using LCD mounting adhesive strips. The LCD is easily removed if needed without voiding your warranty. (strips available separately).

Hp Notebook Pc 15 Dw0035cl 6kl72ua Screen Installation Video

Don't like videos? See our Step by Step generic screen replacement instructions.
See how to find out which model of screen you have.
