Enlarged Image
30 Pins - 19mm wide connector


Error retrieving reviews from the server.

HP 15 DW0XXX Full-HD Replacement Laptop Screen
( Without Touch Glass )

SKU
2290961
Condition
NEW, Class 1 (ISO-9241)
Size
15.6"
Resolution
1920X1080 (FHD) 1080p
Backlight
LED
Touch Screen
NO
Touch Glass
Not included
Finish
Matte (Anti-Glare)
Connector
30 PIN EDP (bottom right)
Connector Pitch
0.5mm (Large)
Display Mode
UWVA
Screen Bezel
HP MicroEdge™ Screen
 ⓘ Specifications Help
Alternative Finish
Glossy / Glare
Alternative Technology Available
60HZ TN
72% NTSC / 100% sRGB
Warning: There may be more than one screen type for your computer. You must choose the correct type. See other options.
£43.14
 + Shipping Costs
Quantity:
Order in the next 20 hours 35 mins 25 secs for UK delivery Tuesday By 1PM

You'll Also Need:
LCD Mounting Strips      Stretch Release Tape£4.99+VAT (What's this?) Stretch Adhesive Tape is a special LCD tape that can be removed easily (unlike double-sided tape), by pulling tabs at the end of the tape.
Have you got the right product?

The currently selected product on this page is a 15.6" 1920X1080 (FULL HD) with a LED backlight and a 30 Pin signal, bottom right connector, with a 0.5mm connector pitch.

This HP computer has other screen types fitted. You must make sure you purchase the correct one which uses the same resolution and connector type.

Can I Upgrade My Screen?    How do I Order By Screen Model?

Prices shown include UK VAT

 Variations of HP 15 DWxxxxxx models screens
Type
Backlight
Price
Trade

 HP 15 DW0XXX 15.6 HD TOUCH
Gloss. Bottom right connector 30 pins (0.5mm)
15.6"
HD
1366X768

LED

£46.74

£43.46

 HP 15 DW0XXX 15.6 HD TOUCH
Gloss. Bottom right connector 40 pins (0.4mm) Touch
15.6"
HD
1366X768

LED

No Stock



 HP 15 DW0XXX 15.6 FULL HD TOUCH
Matte. Bottom right connector 40 pins (0.5mm) Touch
15.6"
FULL-HD
1920X1080

LED

£65.94

£61.32

 HP 15 DW0XXX 15.6 HD TOUCH
Gloss. Bottom right connector 30 pins (0.5mm)
15.6"
HD
1366X768

LED

£46.74

£43.46

 HP 15 DW0XXX 15.6 HD TOUCH
Gloss. Bottom right connector 40 pins (0.4mm) Touch
15.6"
HD
1366X768

LED

No Stock



 HP 15 DW0XXX 15.6 FULL HD TOUCH
Matte. Bottom right connector 40 pins (0.5mm) Touch
15.6"
FULL-HD
1920X1080

LED

£65.94

£61.32



Legend:
    Available to buy online
    Unavailable
HP 15 DWxxxxxx models replacement laptop LCD screen
HP NOTEBOOK PC 15 DW0XXX 15.6 FULL HD LAPTOP SCREEN NO DIGITIZER
15.6"
1920X1080
FULL HD
LED
30 Pin/19mm

Class I Display for HP laptops
This is a replacement screen for the Hp Notebook Pc 15 Dw0xxx (FHD) computer. Class I and fully compatible LCD display part.

HP 15 DWxxxxxx models LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1920X1080 (or is known as FULL HD resolution or 1080p).

Technical data for the HP 15 DWxxxxxx models LCD.
This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles.

100% Compatible part.
For the Hp Compaq Notebook Pc 15 Dw0xxx (FHD). This display will replace many screen makes and models, including (but not limited to), the following part codes: L51997-001   L51998-001

Not Touchscreen. Raw LCD panel only.
HP 15 DWxxxxxx models screens can sometimes come touch screen enabled, this product is a non-touchscreen model. We are supplying the raw LCD panel only without any accompanying front touch glass overlay (digitizer). If your laptop has a screen and a glass covering providing touch screen features you will need the raw LCD and the digitizer glass together. Professionals can separate the old digitizer with a heat-gun (if not damaged), and fit it to the new display. If your laptop is not a touchscreen model, this is the correct product for you.

Cost of HP screen.
Hp Compaq Notebook Pc 15 Dw0xxx (FHD) screen replacement cost is just £43.14 plus shipping.

Warranty
We give an industry leading 2 year warranty on all our high quality HP replacement laptop screens. Terms and conditions apply.

Fast Delivery
UK and Europe only.



Certified Screen Replacement5 Star Rated Icon

Hp Notebook Pc 15 Dw0xxx (fhd) Screen Installation Video

Don't like videos? See our Step by Step generic screen replacement instructions.
See how to find out which model of screen you have.

Warning!

This screen is only for devices with 15.6" displays @ 1920X1080 (FULL HD) resolution with a LED backlight and a 30 Pin signal, bottom right connector, with a 0.5mm connector pitch.

This product is not for touch screen devices. [ Info ⓘ ]

There are different screen type choices for your device on this page. You must choose the correct type. If you are unsure which type to choose, we recommend removing your old screen and searching for the screen model number instead.
