You are at > Home > Laptop Screens > HP (All) > Notebook PC > Notebook PC 17s
×
Enlarged Image
30 Pins - 19mm wide connector


Error retrieving reviews from the server.

HP 17S CU0001TX 456A1PA Replacement Laptop Screen

SKU
2287815
Condition
NEW, Class 1 (ISO-9241)
Size
17.3"
Resolution
1920X1080 (FHD) 1080p
Backlight
LED
Finish
Matte (Anti-Glare)
Connector
30 PIN EDP (bottom right)
Connector Pitch
0.5mm (Large)
Frame Rate
60hz Refresh
Display Mode
UWVA
Screen Bezel
Narrow Border/Narrow Bezel
 ⓘ Specifications Help
£55.14
 + Shipping Costs
Quantity:
Order in 0 Minutes for UK delivery Tuesday By 1PM

You'll Also Need:
LCD Mounting Strips      Stretch Release Tape£4.99+VAT (What's this?) Stretch Adhesive Tape is a special LCD tape that can be removed easily (unlike double-sided tape), by pulling tabs at the end of the tape.
HP Notebook PC 17s replacement laptop LCD screen
HP NOTEBOOK PC 17S CU0001TX 456A1PA 17.3 LAPTOP SCREEN
17.3"
1920X1080
FULL HD
LED 60hz
30 Pin/19mm

Class I Display for HP laptops
This is a replacement screen for the Hp Notebook Pc 17s Cu0001tx 456A1PA computer. Class I and fully compatible LCD display part.

Notebook PC 17s LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 17.3" inches diagonally (not including the frame) and has a maximum resolution of 1920X1080 (or is known as FULL HD resolution or 1080p).

Technical data for the Notebook PC 17s LCD.
This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles.

Easy Mount Display.
This slimline, Narrow-Bezel HP LCD features an ultra-thin frame, that requires no awkward screws, and can be securely mounted, to the laptop's top lid using LCD mounting adhesive strips. The LCD is easily removed if needed without voiding your warranty. (strips available separately).

Cost of HP screen.
Hp Compaq Notebook Pc 17s Cu0001tx 456A1PA screen replacement cost is just £55.14 plus shipping.

Warranty
We give an industry leading 2 year warranty on all our high quality HP replacement laptop screens. Terms and conditions apply.

Fast Delivery
UK and Europe only.



Certified Screen Replacement5 Star Rated Icon

Universal Laptop Screen Installation Video

156,482 views • 23 May 2021  |  Slow Playback? Standard Quality
Don't like videos? See our Step by Step generic screen replacement instructions.
See how to find out which model of screen you have.
