Enlarged Image
30 Pins - 19mm wide connector


Error retrieving reviews from the server.

Lenovo 500W 82J30004MB Replacement Laptop Screen

SKU
1964923
Condition
NEW, Class 1 (ISO-9241)
Size
11.6"
Resolution
1366X768 (HD) 768p
Backlight
LED
Touch Screen
YES
Touch Type
Digitizer Glass
Finish
Matte (Anti-Glare)
Connector
30 PIN EDP (bottom right)
Connector Pitch
0.5mm (Large)
Display Mode
IPS
Includes
Screen, Digitizer & Frame
 ⓘ Specifications Help
Out Of Stock
IBM Lenovo 500 series replacement laptop LCD screen
LENOVO 500W 82J30004MB 11.6 LAPTOP SCREEN
11.6"
1366X768
HD
LED
Touch Screen
30 Pin/19mm

Class I Display for LENOVO laptops
This is a replacement screen for the Lenovo 500w 82J30004MB computer. Class I and fully compatible LCD display part.

IBM Lenovo 500 series LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 11.6" inches diagonally (not including the frame) and has a maximum resolution of 1366X768 (or is known as HD resolution or 768p).

Technical data for the IBM Lenovo 500 series LCD.
This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles. This is a touch screen that includes the digitizer.

Lenovo 500w 82j30004mb Screen Installation Video

Don't like videos? See our Step by Step generic screen replacement instructions.
See how to find out which model of screen you have.
