Enlarged Image
30 Pins - 19mm wide connector


Error retrieving reviews from the server.

Lenovo EDGE 15 80K9000DUS Replacement Laptop Screen
( Without Touch Glass )

SKU
1036050
Condition
NEW, Class 1 (ISO-9241)
Size
15.6"
Resolution
1920X1080 (FHD) 1080p
Backlight
LED
Touch Screen
NO
Touch Glass
Not included
Finish
Matte (Anti-Glare)
Connector
30 PIN EDP (bottom right)
Connector Pitch
0.5mm (Large)
Frame Rate
60hz Refresh
Display Mode
IPS
 ⓘ Specifications Help
Alternative Finish
Glossy / Glare
Alternative Technology Available
60HZ TN
120HZ TN
IBM Lenovo Edge 15 series replacement laptop LCD screen
LENOVO EDGE 15 80K9000DUS 15.6 LAPTOP SCREEN NO DIGITIZER
15.6"
1920X1080
FULL HD
LED 60hz
30 Pin/19mm

Class I Display for LENOVO laptops
This is a replacement screen for the Lenovo Edge 15 80K9000DUS computer. Class I and fully compatible LCD display part.

IBM Lenovo Edge 15 series LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1920X1080 (or is known as FULL HD resolution or 1080p).

Technical data for the IBM Lenovo Edge 15 series LCD.
This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles.

Not Touchscreen. Raw LCD panel only.
IBM Lenovo Edge 15 series screens can sometimes come touch screen enabled, this product is a non-touchscreen model. We are supplying the raw LCD panel only without any accompanying front touch glass overlay (digitizer). If your laptop has a screen and a glass covering providing touch screen features you will need the raw LCD and the digitizer glass together. Professionals can separate the old digitizer with a heat-gun (if not damaged), and fit it to the new display. If your laptop is not a touchscreen model, this is the correct product for you.

Cost of LENOVO screen.
Ibm Lenovo Edge 15 80K9000DUS screen replacement cost is just £44.34 plus shipping.

Warranty
We give an industry leading 2 year warranty on all our high quality LENOVO replacement laptop screens. Terms and conditions apply.

Fast Delivery
UK and Europe only.



Certified Screen Replacement5 Star Rated Icon

Lenovo Edge 15 80k9000dus Screen Installation Video

Don't like videos? See our Step by Step generic screen replacement instructions.
See how to find out which model of screen you have.
